釹磁喇叭
全頻
3.5 Full Frequency Speaker
| Normal Impedance | 8ohm |
| Recommended Frequency Range | 120Hz-12kHz |
| Short Term Power Handling | 50W |
| Long Term Power Handling | 100W |
| Characteristic Sensitivity | 85dB |
| Voice Coil Diameter | 25.5mm |
| DC Resistance of Voice Call Re | 5.6ohm |
| Voice Coil industance @1kHz Le | 1.08mH |
| Force Factor BI | 4.654T-M |
| Free Air Resonance Fo | 127Hz |
| Mechanical Q Factor Qmz | 11.105 |
| Electrical Q factor Oes | 1.053 |
| Total Q Factor Qts | 0.962 |
| Reference Efficiency No | 0.108% |
